Hand Extruder / Plastic Hand Extruder WIN 600C

Plastic Hand Extruder WIN 600C

Plastic Hand Extruder WIN 600C

Plastic Hand Extruder WIN 600C

Plastic Hand Extruder WIN 600C

Plastic Hand Extruder WIN 600C

Plastic Hand Extruder WIN 600C

This extrusion welding gun has the functions of dual independent heating of base material and welding rod, digital temperature control display, 360-degree rotating welding nozzle, motor cold start protection, etc. The shape design of the air blower under the extrusion drill makes It can be welded quickly even in small welding occasions. This welding gun is mainly used for welding HDPE, PP plastic pipes, plastic sheets, plastic decks, plastic water tanks, and plastic film materials.



Double Heating System
Welding rod feed heating system and hot air heating system make sure the best welding quality.

Digital Display Controller
Microcomputer chip control, easy and intuitive operation, strong protection function

360 degree Rotating Welding Head
The 360-degree rotating hot air welding nozzle can be applied to different needs.

Motor Cold Start Protection
Extruding motor will shut down automatically if it has not reached the preset melting temperature,which avoids loss caused by operating mistake.

Model  WIN  600C
Rated Voltage  230V/120V
Frequency  50/60HZ
Extruding Motor Power  800W
Hot Air Power  1600W
Welding Rod Heating Power  800W
Air Temperature  20-620℃
Extruding Temperature  50-380℃
Extruding Volume  2.0-2.5kg/h
Welding Rod Diameter  Φ3.0-4.0mm
Driving Motor  Hitachi
Body weight  6.9kg
Certification  CE
Warranty  1 year

Plastic Hand Extruder WIN 600C
