Hand Extruder / Hot Air Hand Extruder WIN 600B
Hot Air Hand Extruder WIN 600B
This plastic extrusion is the first in China to provide dual independent heating of base material and welding rod, digital temperature control display, motor cold start protection and other functions. This extrusion welding gun uses 3400w hot air blower to heat the base material independently, and is equipped with an anti-scalding design welding nozzle. The Japanese Hikoki electric drill is used as the extrusion motor. It has a small body, convenient operation, strong power, continuous welding. It has high-efficiency welding quality for thick plastic plates. WIN 600B is mainly used for welding of PE, PP and other thermoplastic materials such as plates, membranes, pipes, water tanks, and plastic parts.
Equipped with high power heating unit and Japanese high quality drive motor
The installed 3400W high-power hot air gun provides more heat. High-quality Japanese Hikoki electric drill is selected as the driving motor to meet the needs of professional customers.
Cold Start Protection of drive motor
In addition to the built-in overload protection of the drive motor, our self-developed first start protection function will delay 180 seconds before allowing the start after the digital display temperature reaches the set temperature, which protects and extends the working life of the drive motor to the greatest extent.
Automatic Temperature Compensation Function
In the process of using the plastic extrusion welder, when the temperature of the extrusion screw area changes, the intelligent control system will automatically adjust according to the set temperature.
Model WIN 600B
Rated Voltage 230V
Frequency 50/60HZ
Extruding Motor Power 800W
Hot Air Power 3400W
Welding Rod Heating Power 800W
Air Temperature 20-620℃
Extruding Temperature 50-380℃
Extruding Volume 2.0-2.5kg/h
Welding Rod Diameter Φ3.0-4.0mm
Driving Motor Hitachi
Body weight 6.9kg
Certification CE
Warranty 1 year
